Plasma





Hypertherm’s unrelenting focus is on metal cutting technology. With a continuous stream of innovations to improve cut quality and service life, enhance productivity, and lower operating costs, Hypertherm products have set the standard in the thermal cutting market. With the release of the new HPR-800XD, Hypertherm has a complete line of conventional and precision plasmas up to 800 amps and the ability to production cut 2″ steel.

Today our focus on technology development continues with an expanded range of products for thermal cutting: plasma arc cutting systems, torches and consumables, torch height controls, CNC controls and software for process automation.

HPR800XDHypertherm’s full line of Plasma Cutting Systems, CNC Controls, Automatic Torch Height Control Systems, and Automated Gas Panels allow us to supply fully integrated, turn-key plasma system solutions. Put the power and precision of Hypertherm equipment to work for you.







Burny Kaliburn



Spirit II Plasma Cutter

The Spirit II is a full function FineLine™ high definition plasma cutting and marking system with fully automated or manual process control. Available in 150, 275 and 400 Amp models, it has the ability to pierce most metals up to 2 in. (400 Amp Model) thick. Automatic setting of process parameters provides exceptional ease of operation. The Spirit II provides FineLine™ high definition plasma cut edge quality. It delivers virtually dross free cuts with 2° or less cut edge bevel.

The Spirit II is designed to be the ultimate process tool when precise, square and virtually dross free cuts are important. With ease of use, the ultimate in cut quality and the highest processing speed, the Spirit II truly sets the standard in precision plasma cutting.

Spirit II 400 Pictured

Spirit II Plasma

Download Video: QuickTime (MOV, 11MB)





Auto-Cut® XT Systems

The new Auto-Cut XT systems deliver the next step in flexibility and reliability in heavy plate cutting applications.

Auto-Cut 200 XT & 300 XT systems deliver premium cut performance on both mild steel and non-ferrous metals. These power supplies are designed for reliable, low cost operation. Features like the XT™ 301 consumable parts cartridge and the Machine Status Message Center make the these models easy to operate.



Ultra-Cut® XT Systems

The new Ultra-Cut® XT technology provides the next generation of higher productivity, increased flexibility and confidence in high precision plasma cutting. Ultra-Cut® XT systems give you the flexibility to increase cutting power and the assurance of superior quality, higher productivity and lower cutting costs. Ultra-Cut® XT systems are available in 100 to 400 Amp outputs for cutting plate up to 2″ (50 mm) thick. Their performance will meet or beat anyone on mild steel, and they are superior on non-ferrous metals. With the Ultra-Cut® XT, you never have to worry about choosing the right system.

The next generation of high precision plasma cutters works the way you do — intelligently.










Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com

CNC Controls



Hypertherm’s  Automation Division also offers a complete line of CNC motion control solutions for oxy-fuel and plasma cutting applications. In 2008, Hypertherm released their Phoenix 8.0 software making it the easiest to use motion control system available on the market. C&G Systems now offers the Edge Ti on its Aviator and Challenger series machines, and the MicroEDGE on its Challenger, Crossfire, and Taurus series machines.

Edge Pro

Designed to be flexible and easy to use, the EDGE Pro delivers reliable performance for improved profitability and application performance such as True Hole technology. Using Phoenix software, this CNC improves cut quality and productivity by delivering our expertise directly to your factory, making it as if you have your best operator on every shift.

The EDGE Pro offers multiple back-door interfaces for table manufacturer integration. Providing three analog choices and one SERCOS version, the EDGE Pro interfaces allow the table manufacturer to configure the CNC to match the table design.

EDGE Pro Ti

EDGE Pro TiThe EDGE Pro Ti is designed with integrated drives, motors and multiple torch height control interface options for ease of installation and setup. Combined, the hardware and software empower the operator to make the optimal cut, every time, increasing productivity, and profitability.















Burny Kaliburn





The PLUS is an industrial-grade PC, designed to operate in extreme shop environments where temperature and humidity extremes, metal dust, RF radiation, vibration, and constant machine movement are commonplace. It is easy to learn, easy to use, and
allows multiple control and program tasks to be completed simultaneously.

The Burny 10 LCD PLUS CNC Control produces extremely precise and repeatable motion control by utilizing Windows® XP Embedded (operating system) and tenAsys INtime® (real-time motion control).

The PLUS also contains a large, 15″, full-color, touch screen interface as well as familiar features common to all Burny PRODUCTS: including help screens, 50 shape library, and the ability to create/edit shapes within the control.

 The advanced Phantom II CNC shape cutting controller is designed for use with multiple axis cutting machines. It features an operator console that contains full plasma functionality for 2 plasma stations, up to 6 oxy-fuel stations, a single marker  and auxiliary functions. The new software provides improved flexibility and ease of use    for the operator. The end result is excellent cut quality and high productivity.



The Phantom ST II controller features –

  • Operator console that contains full plasma functionality, up to 2 oxy-fuel stations and 2 plasma stations.
  • Choose between integrated AC drives or external drive interface configurations.
  • New PC platform with advanced multi-core processor technology combined with standard 3 axis drives. Faster processing capability enables advanced CNC features and improves the user experience.
  • Touch screen display with new intuitive user interface that is easy to learn and improves operator productivity.









ICNC®XT

When matched with Thermal Dynamics® innovative Ultra-Cut® with Automatic Gas Control, the iCNC® XT achieves true integrated control and turns the most precise plasma system into one of the easiest to operate. With special features like Dual Microprocessor Control, iCNC XT is an affordable upgrade that can be paired with any plasma cutting system for improved cut quality and performance.








Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com



Height Controls

C&G Systems has established authorized integrator/OEM relationships with the world’s leading manufacturers of automated plasma cutting systems. These relationships allow C&G to offer its customer the widest selection of systems available and work with customers to develop the best application-based solution to their unique plasma cutting challenges.



KALIBURN also offers the INOVA Torch Height Control which accurately maintains torch to plate distance resulting in improved part quality and consumable life. The INOVA is truly the world standard in Torch Height Control and it is a critical part of any precision high current density plasma system.

Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com







arcglide_slide2Traditional torch height controls require operators to periodically adjust arc voltage to ensure proper cut height. Using Hypertherm’s proprietary techniques, The ArcGlide THC continuously samples arc voltage and automatically adjusts arc voltage for proper torch height over the life of the consumables without requiring operator input.

The ArcGlide THC offers optimal cut quality, improved productivity and reduced operating costs for plasma cutting applications including True Hole Technology. Offered in both CNC integrated (with Hypernet communication) and standalone configurations, this THC delivers its benefits with minimal operator intervention required.



The Sensor PHC is an easy-to-use and reliable voltage-sensing height control for conventional plasma applications. The benefits realized are substantial in terms of:

  • Consumable life improvement
  • Improved cut quality
  • Reduced operator intervention

The Sensor PHC offers easy installation on new or existing conventional plasma cutting tables with any CNC and a broad range of plasma systems. Available in several application-specific configurations, the Sensor PHC delivers improved performance at a reduced cost compared to other height control solutions.






Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com

Nesting Software

Reduced Material Costs Hypertherm Cam Solutions is a global leader in CAM nesting software for CNC sheet and plate cutting applications, including plasma, oxy-fuel, laser, water-jet, router, knife, and turret punch applications. ProNest®, TurboNest® and NestMaster® Nesting Software packages provide a single solution to all of your profile cutting needs. Easily import a variety of file formats, create highly optimized nests and output CNC code with the industry’s best user-interface. Hypertherm CAM Solutions will increase your company’s profitability by:

  • Reduced Programming Costs
  • Increased Productivity
  • Increased Part Quality
  • Improved Management Information

Hypertherm CAM Solutions



By selecting Hypertherm CAM Solutions, you will feel comfortable knowing that you have partnered with a company that measures its success by ensuring yours… Power Made Simple!


Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com

Exhaust & Ventilation

Farr Air Pollution Control is dedicated to being experts in industrial dust and fume collection to clean up manufacturing processes. Laser cutting and plasma cutting are two of many industrial dust collection applications that the Farr Gold Series dust collector has been used on.





gold-series-ventilationGold Series units are modular/expandable, feature spark arrestors, automatic filter purge system, and vertically mounted, high-efficiency, easy to change filter cartridges.


Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com

Beveling



C&G Systems has formed a partnership with Saar-Hartmetall to bring its customers some of the finest German-engineered beveling tools in the world. C&G can now offer its customers complete beveling solutions, from hand-held edge-milling machines all the way up to units capable of beveling plate up to 4″ thick and 10′ long. Bevels are produced using either a milling or abrasive belt grinding process on various configurations of machines. Call C&G today to arrange a demonstration and see how you can slash the time you spend beveling while increasing the quality of your bevels.

Gerima Beveling Tools are more than just hand-held bevelers, they are true portable edge-milling machines.  These units are equipped with pneumatic or industrial-duty variable speed 1.5-2.5 horsepower motors. Carbide inserted cutting heads allow you to quickly, consistently, and repeatedly cut bevels up to 40mm and radius edges up to 15mm. The standard cutting head cuts 45 degree bevels and radii, and additional cutting heads are available to bevel angles from 10 degrees to 80 degrees. These hand-held units are extremely flexible and can quickly and accurately bevel difficult contours and holes as small as 2″ diameter.

The PAM, KFM, and FASRAPID lines provide straight-segment beveling solutions for medium to high production environments. All three models feature automatic feeding systems to control quality of bevel and provide maximum operator safety.

The PAM series of machines can produce up to 20mm bevels and the KFM series of machines can produce up to 30mm bevels. Both machines have bevel adjustment from 10-60 degrees and are ideal for beveling coupon size parts. The KFM series also has the ability to produce radius edges from 2mm-6mm.

The FASRAPID line provides ultimate beveling capability. This unit can put a 60mm (2.35″) bevel from 0-80 degrees on material as thick as 100mm (4″) and 3M long (10′). Bevels are produced using a unique oscillating abrasive belt technology.

In addition to these units, Saar-Hartmetall also produces a complete line of pipe beveling equipment. Please contact C&G Systems for complete information (sales@cgsystems.com), or visit their website to see videos of all of their units in action, and be sure to tell them C&G sent you!


Let C&G Systems’ highly experienced sales staff evaluate your application and requirements to determine which combination of table, plasma, and control will be best for you. Contact us today at sales@cgsystems.com
